Multilayer Rigid-Flex
Combining multiple rigid areas with several flexible layers. Ideal for complex medical devices and industrial controllers.
- Up to 20+ layers
- Air-gap construction
- Fine-pitch component support
Seamlessly integrating flexible and rigid substrates to eliminate connectors, reduce weight, and maximize space in high-performance electronics.
Combining multiple rigid areas with several flexible layers. Ideal for complex medical devices and industrial controllers.
Engineered for continuous bending applications like hinges or scanner heads with high cycle counts.
Request Quote
Integrating Blind & Buried vias within hybrid constructions for the ultimate high-density interconnect requirements.
| Feature | Rigid PCB | Flexible PCB | Rigid-Flex |
|---|---|---|---|
| 3D Space Usage | Limited (Flat) | Excellent (Foldable) | Best (Self-Supporting) |
| Reliability (Vibration) | Medium | High | Excellent (No Connectors) |
| Component Support | Excellent | Moderate | Full (on Rigid sections) |
| Weight Reduction | Low | High | Optimal Hybrid |
Preparing the polyimide flexible cores with copper etching and coverlay application to define the bending sections.
Sequential lamination of rigid FR-4 layers onto the flex core using specialized "No-Flow" prepreg to prevent resin leakage.
Mechanical and laser drilling across different substrates followed by plasma desmear for plating reliability.
Outer layer circuit definition, surface finish, and 100% E-test/AOI for signal integrity across all interfaces.
